Hebei Hengya Conveyor Equipment Co., LtdStainless steel roller
Scope of application: Accessories for conveyors
Diameter: customizable
Length: 190-3000mm
Weight: 5-35kg
Shelf life: 1 year
Introduction: Stainless steel rollers are mainly used under the iron remover of underground or power plant belt conveyors to prevent the stainless steel rollers from being sucked up by the iron remover. Because the roller is located at the head of the tape machine and is subjected to significant impact, the roller tube, roller shaft, and bearing
product details
Stainless steel rollers are mainly used under the iron remover of underground or power plant belt conveyors to prevent the stainless steel rollers from being sucked up by the iron remover. Because the roller is located at the head of the tape machine and is subjected to significant impact, stainless steel is used for the roller tube, roller shaft, bearing seat, bearings, and shaft
Uses
Applied to industries such as mining, coal, petroleum, fertilizer, grain, environmental protection, etc., it is used for seam screen mesh, petroleum filter mesh, and salt industry mesh.
Working principle of roller
The roller drives the roller tube, bearing seat, outer ring, and sealing ring to rotate through the frictional force between the conveyor belt and the roller, and together with the conveyor belt, achieves the transportation of logistics.
Stainless steel rollers are available in large quantities in stock and can be customized!
The overall quality of stainless steel idler rollers depends on the shape of the rollers in the structure, processing quality, bearings, and bearing cup lubricating grease. At present, the new type of oil injection roller used in developed countries has low operating resistance, and the bearings are lubricated with thin oil. The belt speed of the drum can reach 6-8 meters per second, and its service life can exceed 10 years
Product Features
- The weight has been further reduced (only about one-third of the weight of the original ordinary roller), and the rotational resistance and moment of inertia have been further reduced, resulting in a more significant energy-saving and consumption reducing effect;
- The mechanical performance and wear resistance are significantly improved compared to ordinary steel pipes, and although the wall thickness is reduced, the service life will not be affected in any way;
- Its corrosion resistance is self-evident;
- Magnetic isolation is also well-known;
- More reliable hygiene performance;
- It can significantly reduce the labor intensity of roller installation.
